Laser Curtains and Screens

Laser Curtains and Screens

LAZE BLOK - Specialty Laser blocking material for industrial laser applications. Black and White in color. Intended to stop stray laser radiation from escaping a laser controlled area. CE and approved per EN60825-4:1997. Can be used to block lasers of all wavelengths between 180 and 10600 nm. Specific statements for PEL based on each incidence/application.

Overview:

  • Stops stray laser radiation from escaping a laser controlled area.
  • Protects those outside laser area from exposure and need for PPE.
  • All screens are CE marked and certified to EN60825-4 specifications.

Features and Benefits:

  • Blocks lasers of all wavelengths between 180 and 10600nm (inclusive).
  • Black on one side white on the other - white side should always face the laser operation.
  • Laser material can be attached to our Defender and Guardian Automated Barrier Doors for automated laser enclosures.
  • Curtains can be free hanging off our curtain hardware.
  • Available as free standing powder coated steel framed screens for easy mobility with locking casters.
  • Free standing HD laser blocking screen; for all laser wavelengths; Size: 7.7' x 6.5' (h).
  • Free standing HD laser blocking screen; for all laser wavelengths; Size 3.9' x 6.5'(h).

Technical Information:

Protection times in excess of 100 sesconds are achieved for the following power densities and areas:
3 MW/sqm over 1 sq mm
0.7 MW/sqm over 500 sq mm
The material will block lasers of all wavelengths.

Irradiated Area

PEL (T3) 10 s

PEL (T2) 100 s

4 mm2

61 MW/m2

34 MW/m2

2000 mm2

2.7 MW/m2

1.5 MW/m2
